Kinetex XB-C18 Core Shell
Kinetex XB-C18 Core Shell HPLC Column offers increased retention of acidic compounds and peak shape
Kinetex XB-C18 Core Shell
Kinetex XB-C18 Core Shell
A Unique Core-Shell Selectivity
Di-isobutyl side chains differentiate this C18 column. Low ligand density and an inactive surface make this column a great hydrogen bond acceptor. This phase will demonstrate improved peak shape and increased retention of acidic compounds.
- Compatible with all Analytical HPLC/UHPLC Systems*
- Unique C18 Retention (USP: L1)
- Improved Selectivity of Acidic compounds
*Kinetex analytical columns are compatible with all LC system with standard LC column end-fittings threaded in 10-32. Please contact us at Phenomenex.com/chat for any questions and information about fitting compatibility and any other column internal diameters.
Carbon Load 10 (effective), 10.0, null %, 10 (effective) %, 10.0 % |
Surface Area (m²/g) 200 |
Particle Size 1.7, 2.6, 3.5, 5 |
Recommended Use Superior peak shape and enhanced separation of basic compounds under neutral and acidic conditions |
Selectivity for Acidic Compounds
This unique C18 phase yields increased hydrogen bonding with hydrophobic selectivity‚ resulting in improved peak shape for basic compounds and increased retention of acidic compounds.
Complementary Core-Shell C18 Phases
Ultra-high performance columns like Kinetex will give you very narrow peaks, but without the right selectivities you are left with very narrow, overlapping peaks. The phases offered in the Kinetex column line are complementary to one another, so the spectrum of selectivity your separations require is covered.
C18 Phases (C18 vs. XB-C18)
Conditions for all columns:
Dimension:
50 x 2.1 mm
|
|
Mobile Phase:
A: Water B: Acetonitrile |
|
Gradient:
Time (min)
0
6 6.01 8 | % B
20 60 20 20 |
Flow Rate:
0.5 mL/min |
|
Temperature:
30 °C |
|
Detection:
UV @ 220 nm (ambient) |
|
Samples:
1. Estriol 2. Hydrocortisone 3. Cortisone 4. Estradiol 5. Cortisone-21-acetate 6. 21-Hydroxyprogesterone 7. Estrone 8. 17-Hydroxyprogesterone 9. Deoxycorticosterone acetate |
|
Manipulate Acidic and Basic Compound Retention
Find the right phase selectivity for your application by investigating the diverse selectivity availability of the Kinetex Core Shell HPLC and UHPLC columns. Where reliable performance meets unique selectivity.
Conditions for all columns:
Dimension:
50 x 2.1 mm
|
|
Mobile Phase:
A: Water with 0.1% Formic Acid B: Acetonitrile with 0.1% Formic Acid |
|
Gradient:
Time (min)
0
0.2 4.2 4.21 5.5 | % B
5 5 95 5 5 |
Flow Rate:
0.8 mL/min |
|
Temperature:
30 °C |
|
Detection:
UV @ 245 nm (ambient) |
|
Samples:
1. Pyridine 2. Acetaminophen 3. Pindolol 4. Quinidine 5. Sulfathiazole 6. Acebutolol 7. Benzyl alcohol 8. Chlorpheniramine 9. Phenol 10. Triprolidine 11. Nortriptyline 12. Prednisolone 13. 3-Methyl, 4-nitrobenzoic acid 14. 2-Hydroxy, 5-methylbenzaldehyde 15. Diflunisal 16. Hexanophenone |
|
